- Base trailer
- All-aluminum
- Deck
- 7' × 14'
- Clear interior cargo
- 81″ W × 168″ L × 84″ H
- Rear clear opening
- 76″ W × 83″ H
- Axles
- 2 × 3,500 lb axles
Base trailer renderManufactured by FWM Inc. in Hudson, New Hampshire50+ years of aluminum manufacturing500+ completed builds documented in the Rugged archive
Enclosed · Tandem axle
Rugged 7 × 14 Enclosed
The contractor core model with tandem-axle stability and room for organized trade equipment.
$9,085
Enter ZIP for your exact estimate
Built after approval. Rugged manufactures your trailer after the final Build Order is confirmed, so you configure the exact version your work requires.
Calculate delivery to your ZIP
Enter your ZIP for Rugged Home Delivery from our Hudson, NH factory.
Enter your ZIP for an exact Rugged Home Delivery price.
Tax, title, registration, and related fees are paid by you in your home state when you register the trailer, if applicable; Rugged does not collect or handle them.
- Deck
- 7' × 14'
- Clear interior cargo
- 81″ W × 168″ L × 84″ H
- Rear clear opening
- 76″ W × 83″ H
- Axles
- 2 × 3,500 lb axles
Fit and towing: Payload shown is trailer payload, not your tow vehicle's capacity. Verify your vehicle, hitch, tongue-weight, and loaded-trailer ratings before ordering.
- Production: about 3 weeks after Build Order approval
- Pickup: Hudson, New Hampshire
- Warranty: Five years on the aluminum structure for retail use, one year for commercial use, with no warranty registration to file.
- Request a live factory video walkaround
Remote-buying confidence
See it before ordering.
Choose the proof you need before reserving.
Construction
Every component earns its place
See the materials, dimensions, and rated components used in this model family.
- 01All-aluminum structural frame
Structural aluminum shell
Main rails, crossmembers, wall studs, and roof bows form the enclosed body structure.
- 02Lockable enclosed body
Lockable cargo body
The enclosed V-nose body protects tools and cargo from weather and casual access.
- 03Factory-engineered upfits
Configured access
Choose compatible rear-door, side-door, interior, and electrical options in the configurator.
Capacity and specifications
The numbers that define the trailer
Essential measurements stay visible. Detailed construction and running-gear information is organized below.
Weight and payload estimates: Published trailer weight reflects the standard base configuration. Options and manufacturing variation affect final weight and available payload. Your completed trailer is weighed at the factory; its certified final weight and payload are provided after manufacturing.
- Pending production validation
- Pending production validation
Cargo space
- Clear interior cargo
- 81″ W × 168″ L × 84″ H
- Interior height
- 84″ full standing height
- V-nose depth (beyond the straight box)
- 25″
- Nominal floor area
- 98 sq ft
Doors & access
- Rear clear opening
- 76″ W × 83″ H
- Side-door clear opening
- 33″ W × 83″ H
Towing & road footprint
- Overall road dimensions
- 102″ W × 234″ L × 103″ H
- Deck height
- 17″
- Hitch height
- 16″
- Axle configuration
- 2 × 3,500 lb axles
Construction
- Structural frame
- All-aluminum structural frame
- Main frame
- 2 × 5 × 3/16″ rectangular aluminum tube
Ratings
- GVWR Rating
- 7,000 lb
Engineer-measured working dimensions for planning your build. Your final Build Order confirms the production specification before fabrication.
All items listed are standard equipment unless marked.
Download spec sheet (PDF)Will your vehicle tow this trailer?
Enter what you know about your tow vehicle for plain-language guidance. This is separate from the trailer's own cargo payload, and it is not a safety certification.
Compare the family
Other sizes
Compare the major differences before opening another model.
Questions
Frequently asked questions
Ready to build
Build your Rugged 7 × 14 Enclosed
Choose a starting configuration, then adjust every available option and see the current price.
